PS55 is the replacement product for PS50
PS55 TECH SPECS
ARTICULATED TV WALL MOUNT 55"-75"
Part of the smoothest and most reliable articulated TV wall mount range on the market, the PS55 bracket’s unique scissor arm design allows perfect parallel movement and easy one handed operation even with heavy screens. Suitable for screens from 55” to 75” the PS55 Manual Articulated TV Wall Bracket is ideal for use either a pull and turn bracket, or a maintenance bracket.
- Hook on/off screen mount enables fast and easy one person fitting, even with larger screens
- Uniquely designed scissor arm for safe and smooth movement, with minimal effort required
- Designed to mount onto a single stud for simple installation
- 16” stud bay mounting kit (PS-SRK) available separately for twin stud mounting, with horizontal bracket offset possible
- In built cable tie anchors for neat and simple cable management with included cable ties
- Minimum depth from wall of 2" makes it one of the thinnest brackets available
| THE PS BRACKET IS AVAILABLE IN A RANGE OF SIZES TO SUIT DIFFERENT INSTALLATIONS | ||||
|---|---|---|---|---|
| APPROX SCREEN SIZE | MAX EXTENSION FROM WALL | MAX SWIVEL | MAX WEIGHT | PRODUCT |
| 32 - 43" | 300MM (11.8") | UP TO 50° (SCREEN WIDTH DEPENDENT) |
60KG (132LBS) | PS32 |
| 40 - 75" | 400MM (15.7") | UP TO 50° (SCREEN WIDTH DEPENDENT) |
60KG (132LBS) | PS40 |
| 55 - 75" | 500MM (19.7") | UP TO 50° (SCREEN WIDTH DEPENDENT) |
60KG (132LBS) | PS55 |
| 65 - 75" | 595MM (23.4") | UP TO 50° (SCREEN WIDTH DEPENDENT) |
60KG (132LBS) | PS65 |
| 80 - 110" | 569MM (22.4") | UP TO 45° (SCREEN WIDTH DEPENDENT) |
120KG (265LBS) | PS80 |
THE ORIGINAL
CUSTOM INSTALL BRACKET
The PS bracket is the perfect TV wall solution for any room, whether it be the bedroom, kitchen or family living area, it helps to give users the perfect viewing experience every time. Time saving installation features such as cable tie anchors, a hook on/hook off screen mount and full compatibility with our WB In Wall Box range make the PS bracket range a firm favourite with our dealers.
The already super slim 50mm [2.0”] profile on the wall can be further reduced with recess mounting or by combining the PS bracket with one of our WB In Wall Mounting boxes, while the standalone PS bracket works flawlessly with our USM Universal Speaker Mount and AM Accessory Mount.
HAND CRAFTED IN HOUSE
TECHNICAL SPECIFICATION
| PRODUCT CODE | PS55 |
|---|---|
| CABLE MANAGEMENT | IN-BUILT CABLE TIE ANCHORS & CABLE TIES INCLUDED |
| FINISH (CUSTOM AVAILABLE) | BLACK PAINT - RAL 9005 |
| MAX EXTENSION FROM WALL | 500MM (19.7") |
| MAX ROTATION |
UP TO 50° EACH WAY (SCREEN WIDTH DEPENDENT) EXAMPLE:
|
| MAX WEIGHT | 60KG (132LBS) |
| MIN DEPTH FROM WALL | 52MM (2") |
| MOVEMENT TYPE | MANUAL |
| SCREEN SIZES (APPROX) | 55" - 75" |
| SHIPPING INFORMATION | |
| SHIPPING DIMENSIONS | 75 x 41 x 12cm (29.5 x 16.1 x 4.7") |
| SHIPPING WEIGHT | 13kg (29lbs) |
| DOWNLOADS / SUPPORT | |
| TECHNICAL SHEET |
 PS55 TECH
|
| INSTRUCTIONS |
PS55 INSTRUCTIONS
|
| CAD |
 PS55 CAD
|
