AL965 TECH SPECS
TELESCOPIC TV LIFT FOR 50"-65" SCREENS
The AL965 is the larger of our two TV Actuator Lift Mechanisms and shares the same great features as the smaller AL675. Suitable for screens from 50” to 65”, the near silent motor makes this lift ideal for both residential and commercial installations.
The AL965 mechanism ships with both a fixed lid and a push-flap mounting option as standard so you can finalise your cabinet design after ordering. As with all Future Automation automated mechanisms, IR, Contact Closure, and RS232 control options as supplied standard.
- In-built cable management chain ensures cables are securely stowed for safe mechanism operation and a neat finish
- Smooth and efficient movement, combined with a near-silent motor, make this lift ideal for residential installation
- A telescopic actuator motor enables height-efficient cabinet design, requiring only 75mm (2.95”) of height above the screen
- Push flap and fixed lid options included as standard to allow for a flexible install, as well as base joinery panel mounting brackets to enable a complete cabinet finish
- Supplied with IR, Contact Closure, & RS232 control options as standard (RF version available)
COMPACT DESIGN
MAXIMUM EFFECT
The AL965 combines clever engineering with high-quality manufacturing to provide consumers with an amazing product that performs flawlessly time after time. This mechanism includes both a fixed lid and push flap mounting option as standard in case your client changes the cabinet style after ordering.
The AL965’s base panel joinery mounting bracket ensures there is no gap at the top of the cabinet under the TV when it is extended and in use, giving the product a seamless, safe and professional finish. The unit can be ordered with either the standard Push Up Lid or an option Fixed Lid system, enabling installers to offer their customers multiple cabinet styles.
The AL965’s functionality can further be enhanced by using it alongside other Future Automation products such as the USM (Universal Speaker Mount), or the SAC-U1 or SAC-U2 Smart Airflow Control units which can be connected to the lift cabinetry to aid the natural convection inside the space.
HAND CRAFTED IN HOUSE
TECHNICAL SPECIFICATION
| PRODUCT CODE | AL965 |
|---|---|
| CONTROL BOX DIMENSIONS | 150 X 307 X 52MM (5.9 X 12.1 X 2") |
| CONTROL OPTIONS | RS232 / CONTACT CLOSURE / IR (RF VERSION AVAILABLE) |
| DECIBEL RATING | 50DB |
| FINISH (CUSTOM AVAILABLE) | BLACK PAINT - RAL 9005 |
| LID TYPES AVAILABLE | PUSH FLAP AND FIXED LID INCLUDED AS STANDARD |
| MAX ELEVATION | 965MM (38") |
| MAX SCREEN HEIGHT | 930MM (36.5") |
| MAX WEIGHT | 40KG (88LBS) |
| MOVEMENT TYPE | MOTORISED |
| OUTPUT POWER SUPPLY | YES(12V) |
| POWER CONSUMPTION | MAX 200W |
| POWER CONSUMPTION (STANDBY) | 3W |
| POWER SUPPLY | 240V OR 110V |
| SCREEN SIZES (APPROX) | 50-65" (APPROX) |
| SHIPPING INFORMATION | |
| SHIPPING DIMENSIONS | 91 x 55 x 29cm (35.8 x 21.5 x 11.2") |
| SHIPPING WEIGHT | 40kg (88lbs) |
